KGF-90D
Type:KGF-90D.
Adaptive voltage:380V power supply provided by gasoline generator.
Rated air volume:50000~71000m³/h.
Control system:High Power Inverter.
Rated speed:580r/min.
Ram diameter:870mm.
Rated power:6~10KW
Wind pressure:500~650pa.
Blade material:Fiberglass or aluminum alloy.
KGF-150F
Name | Fixed lawn ventilation and cooling fan |
Specification and model | KGF-150F |
brand | NAHE |
Brand dimensions
| L | 1230MM |
W | 1508MM |
H | 2460MM |
Main motor model | YDS2100B3-6P-7.5KW |
Rated voltage | 380V |
Main fan speed | 960r/min |
Model of swing motor | M6250-502-8GU-180K-US52 |
Effective perception distance | 50m+ |
Effective ventilation area | 3500㎡+ |
Fan blade | 12 adjustable aluminum alloy blades |
Adjust elevation up and down | 30° |
Swing range | 0~175° |
Gyratory device | Heavy duty slewing bearing |
Standard wind speed (blade safety matching angle) | 18m/s |
Standard air volume | 76000m³/h |
Starting aid | Auxiliary starting of frequency converter |
other | 12 atomizing nozzles and water rings |
